A spider carries something remarkably close to a book inside its abdomen. Book lungs are respiratory organs formed from a chamber containing dozens of extremely thin, closely stacked plates called lamellae, arranged rather like the pages of a book. Air enters through a small opening on the underside of the abdomen and circulates through the narrow spaces between them, while haemolymph flows within the lamellae. Oxygen and carbon dioxide diffuse across these extraordinarily thin surfaces. The architecture solves a geometric problem: a relatively small cavity can contain an enormous respiratory surface without requiring a correspondingly enormous organ. The spider itself solves nothing. It inherits an architecture refined across evolutionary time, one in which biological material has been arranged to multiply the interfaces across which exchange can occur.
The same structural strategy appears throughout biology at radically different scales. Human lungs branch repeatedly until hundreds of millions of alveoli provide an immense exchange surface within the chest; the small intestine uses folds, villi and microvilli to multiply absorption; mitochondrial cristae increase the membrane available for cellular respiration; cortical grey matter folds into gyri and sulci, allowing a much larger cortical sheet to occupy the finite volume of the skull. Geoffrey West’s work on biological scaling approaches the same general problem through branching networks: living systems must distribute energy and materials across increasingly large and complex bodies while remaining within severe geometric and energetic constraints. Folding, branching, stacking and subdivision are different solutions to a recurrent problem. A system does not gain capacity only by becoming larger. It can reorganise its internal structure so that vastly more productive interfaces exist within essentially the same external boundary.
The book lung consequently suggests a principle considerably larger than respiration. Internal differentiation can produce functional capacity far beyond any simple one-to-one correspondence between the amount of material present and what that material can do. Once elements are arranged so that relations themselves become productive, additional capacity appears between them: more surfaces for exchange, more pathways through a network, more possible configurations of a finite set of components. Information carries this principle still further because relational possibilities can multiply without an equivalent increase in physical extent. A finite alphabet generates an effectively unbounded field of expression because its elements can be combined, nested, repeated and recursively related. The deeper principle is not folding itself. Folding is one particularly beautiful physical instance of something more general: complex systems multiply what is possible without proportionately increasing their physical extent, generating greater functional capacity through the interfaces among their parts.
References
Brunelli, E., Rizzo, P., Guardia, A., Coscarelli, F., Sesti, S. and Tripepi, S. (2015) ‘The ultrastructure of the book lungs of the Italian trap-door spider Cteniza sp. (Araneae, Mygalomorphae, Ctenizidae)’, Arthropod Structure & Development, 44(3), pp. 228–236. doi: 10.1016/j.asd.2015.03.001.
Helander, H.F. and Fändriks, L. (2014) ‘Surface area of the digestive tract – revisited’, Scandinavian Journal of Gastroenterology, 49(6), pp. 681–689. doi: 10.3109/00365521.2014.898326.
Ochs, M., Nyengaard, J.R., Jung, A., Knudsen, L., Voigt, M., Wahlers, T., Richter, J. and Gundersen, H.J.G. (2004) ‘The number of alveoli in the human lung’, American Journal of Respiratory and Critical Care Medicine, 169(1), pp. 120–124. doi: 10.1164/rccm.200308-1107OC.
Purves, D., Augustine, G.J., Fitzpatrick, D., Katz, L.C., LaMantia, A-S., McNamara, J.O. and Williams, S.M. (eds.) (2001) Neuroscience. 2nd edn. Sunderland, MA: Sinauer Associates.
West, G. (2017) Scale: The Universal Laws of Life, Growth, and Death in Organisms, Cities, and Companies. New York: Penguin Press.
Daedelus Kite
One reply on “The Spider That Is Bigger on the Inside: Book Lungs and the Geometry of Complexity”
The book lung points to a recurrent property of living systems: biology harnesses geometric depth. Folding, branching, compartmentalisation and network formation multiply interfaces without requiring proportional increases in physical extent. The same principle appears in membranes, lungs, intestines, nervous systems and brains. Internal differentiation creates further surfaces, pathways and relations, expanding what a finite material system can do. Life repeatedly builds complexity this way: existing structure becomes the material for further structure, increasing the relational possibilities available within it. The book lung is a particularly clear instance because the mechanism is visible. Geometry itself becomes functional.
This raises a more general question about structure. Geometry works because some relations recur reliably: distances, proportions, symmetries and transformations persist sufficiently for structures to form and remain coherent. Biology exploits these regularities, but did not create them. Follow them backwards and the question becomes the familiar one of physical law and mathematical structure: where does the regularity reside? It need not reside anywhere outside the system. Any persistent entity already instantiates regularities in the relations from which it is constituted; without them, it could not persist as that entity. Regularity and persistence are the same problem viewed from different directions. Physics describes these persistent relational regularities at one scale; mathematics describes their abstract structure. The book lung sits much further downstream, but the continuity is important: its extraordinary internal geometry is possible because structured relations persist long enough for further structure to be built from them.
